PPW Link

PPW Link (PPWL) is a web service to allow PPW systems to transfer data between accounts. These accounts can be in the same environment or different environments. This was implemented to support PPW enterprise customers. Can also support any other integrations that would like to use the same processes.

Setup PPWLink

Using your PPW account, login to the system. Go to the Admin > Auto Import - Work Orders page. Click the Setup New Import button in the toolbar. The Import From field should be set to PPW Link - Property Pres Wizard-v2. Set the client company to the desired value. Enter the PPW account username and password. The PPW Link URL should point to the receiver script of your integration.

When the Auto Import record is saved the validate_user event will be called. This event will pass the PPW Link Push URL along with verifying the authentication info is correct.

The remote_site_id is a unique UUID. You should generate a UUID and use this UUID for all responses to PPWL. A unique UUID can be generated at the site GUID Generator

PPWL uses HTTP POST to transfer all data. The basic structure of each request is similar. A single POST variable called “payload” is sent that contains the PPWL data. The contents of the “payload” variable is a JSON encoded string.

The PPWL’s production url is https://www.propertypreswizard.com/api/link/receiver.php

The “payload” fields are as follows

The password is a sha1 hash of the PPW password.

Example call with event data in JSON format. The examples are all shown using the curl program. But any standard HTTP programming interface should work fine.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "ppwl_event_name",
  "event_data": "{}"
}

Curl command line example

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "validate_user",
    "event_data": "{}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Responses from PPWL will be in the JSON format with the following fields.

Response JSON

{
   "remote_site_id":"1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
   "error":false,
   "success":true,
   "return_error_msg":null,
   "result_data":null
}

Suggested Data Flow

Authentication

• validate_user – Validate User

validate_user – Validate User

Use the documentation for validating a user from the previous section to see what is going to be sent. The ppwlink_push field from the request event_data can be used to alert PPW that new orders have been assigned to the account. Pinging this URL will force PPWL to check for new orders. The get_all_orders event will be added to the event queue and ran shortly after. Timing will depend on system load and other events in the queue but usually less than a minute.

Request payload JSON

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "validate_user",
    "event_data": "{\"ppwlink_push\":\"https://www.mysite.com/api/push.php?key=myrandomkey\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response for invalid authentication (JSON)

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": false,
  "return_error_msg": "Could not validate username and password.",
  "result_data": "",
  "error": true
}

Work Order Events

• get_all_orders – Gets all OPEN Work Orders
• get_cancel_orders – Gets all CANCELLED Work Orders
• get_all_updates – Gets all updates for Work Orders
• get_order – Gets specific Work Order Information
• get_foh – Gets FOH (front of house) Photo for a WO
• mark_order_imported – Marks Work Order as Imported

get_all_orders – Get Open Orders

Work orders that are in the status Unread, In Field, Follow Up, Accepted, and Rejected are sent through this action.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_all_orders",
  "event_data": "{\"timestamp\":\"1491699142\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_all_orders",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

A timestamp can be passed in the event_data field. If this is sent, only work orders that have been modified after the date are sent. This allows incremental checks for new orders. We would suggest doing a full import at least once a day to make sure all orders are captured.

The response will contain an array of objects for each work order. The result data will have the PPW internal Report ID, the Work Order #, and the PPW #. Using these fields, you should track each work order and if it has been received yet. Any new work orders will then be imported using the get work order event.

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "report_id": "12249320",
      "wo_number": "import test 3-1",
      "org_wo_num": "2272",
      "wo_status": "Unread"
    },
    {
      "report_id": "12249453",
      "wo_number": "import test 3-5",
      "org_wo_num": "2298",
      "wo_status": "Unread"
    },
    {
      "report_id": "12249455",
      "wo_number": "import test 3-6",
      "org_wo_num": "2299",
      "wo_status": "Unread"
    },
    {
      "report_id": "12249459",
      "wo_number": "import test 3-7",
      "org_wo_num": "2300",
      "wo_status": "Unread"
    },
    {
      "report_id": "12249473",
      "wo_number": "import test 3-7",
      "org_wo_num": "2301",
      "wo_status": "Unread"
    }
  ]
}

get_cancel_orders – Get Cancelled Orders

Work orders that have been canceled will be available with the get_cancel_orders event. The timestamp value in the event data is required for this event call. The timestamp cannot be greater than 30 days in the past.

Request payload JSON

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_cancel_orders",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "error": false,
  "return_error_msg": null,
  "result_data": [{
      "report_id": "12255349",
      "wo_number": "PPWTEST3",
      "org_wo_num": "44309",
      "wo_status": "Cancelled",
      "cancel_timestamp": "1529897535"
    },
    {
      "report_id": "12255376",
      "wo_number": "PPWTEST12",
      "org_wo_num": "44336",
      "wo_status": "Cancelled",
      "cancel_timestamp": "1529895967"
    }
  ]
}

get_all_updates – Retreive Updates on Existing Orders

Retreiving updates to work orders is done with the get_all_updates event. A timestamp can be passed and only updates since that time will be sent. This will only send work orders that are currently in an open status for the user.

Work orders can be returned to the vendor (RTV) by setting the wo_status to RTV. The reason for the followup will be passed in the update_value field.

Fields that can be updated are as follows

• address
• city
• comments
• cust_text
• date_due
• key_code
• loan_number
• loan_type_other
• lock_code
• lot_size
• mortgage_name
• start_date
• state
• zip

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_all_updates",
  "event_data": "{\"timestamp\":\"1491699142\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_all_updates",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "report_id": "12249320",
      "wo_number": "import test 3-1",
      "org_wo_num": "2272",
      "wo_status": "In Field",
      "update_field": "lot_size",
      "update_value": "45,000 sqft"
    },
    {
      "report_id": "12249453",
      "wo_number": "import test 3-5",
      "org_wo_num": "2298",
      "wo_status": "In Field",
      "update_field": "comments",
      "update_value": "These are new comments"
    },
    {
      "report_id": "12249320",
      "wo_number": "import test 3-1",
      "org_wo_num": "2272",
      "wo_status": "RTV",
      "update_field": "",
      "update_value": "Take better photos of exterior debris."
    }
  ]
}

get_order – Get Work Order

The work order info, line items and PCR forms are sent using this event.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_order",
  "event_data": "{\"report_id\":\"12249320\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_order",
    "event_data": "{\"report_id\":\"12249320\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

The response will contain an array of objects for each work order. The result data will have the PPW internal Report ID, the Work Order #, and the PPW #. Using these fields you should track each work order and if it has been received yet. Any new work orders will then be imported using the get work order event.

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",

  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "wo_number": "import test 3-1",
    "client_company_alias": "Test Client",
    "cust_text": "Investor",
    "loan_number": "XXXXXXX1234",
    "loan_type_other": "CONV",
    "date_received": "20170331",
    "date_due": "20170415",
    "start_date": "20170402",
    "address": "123 Test Dr",
    "city": "Tiffin",
    "state": "OH",
    "zip": "44883",
    "comments": "",
    "work_type_alias": "Inspection",
    "mortgage_name": "",
    "line_items": [{
      "desc": "Inspection",
      "qty": "0.00",
      "price": "0.00",
      "total": "0.00",
      "add": ""
    }],
    "pcr_forms": [{
      "pcr_form_id": "6318",
      "form_id": "Exterior_Inspection",
      "form_ver_id": "1",
      "form_required": "0"
    }],
    "ppw_report_id": "12249320",
    "import_user_id": null,
    "key_values": {
      "bg_checkin_provider": "ags"
    },
    "lot_size": "",
    "lock_code": "",
    "key_code": "",
    "broker_name": null,
    "broker_company": null,
    "broker_phone": null,
    "broker_email": null,
    "vendor_id": "johndoe",
    "has_foh": true
  }
}

The key_values object can be used to set the check in provider. The only option currently is “ags”. This will set the check in provider to Aspen Grove Solutions. Leaving it blank or not even sending the value will require the default PPW mobile check in.

The vendor_id field in the get_order response is not required. If the field is used, it will need to be the username of a PPW user in the account being imported into. If the user exists, it will automatically be assigned to the user. The user needs to be active.

The has_foh flag indicates that the work order is for a property that has a Front of House photo. When the order is processed, it will queue the event to retrieve the Front of House photo from the client.

get_foh – Get Front of House Photo

The get_foh event will return a direct link to the property’s Front of House photo. When an order is imported for a property that has a Front of House photo, a flag will be set in the json of the work order called has_foh which will be set to a boolean true or false. When the work order is later processed in PPW, the “get_foh” event will be queued for that work order. When this event is processed, the following payload will be sent to the client:

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_foh",
  "event_data": "{\"remote_report_id\":\"12249320\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_foh",
    "event_data": "{\"remote_report_id\":\"12249320\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

This will return a direct link to the front of house photo along with the numeric value of the file size in megabytes rounded to the nearest whole number:

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "s3_url": "https:\/\/link-to-photo.com",
    "file_metadata": {
      "file_size": "7"
    }
  }
}

File metadata fields

mark_order_imported – Mark Order as Imported

This will mark the work order as imported and will set the status of the work order in the PPW system it was imported from to In Field. An entry will also be put in the work order Access History indicating the work order was imported.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "mark_order_imported",
  "event_data": "{\"report_id\":\"12249320\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "mark_order_imported",
    "event_data": "{\"report_id\":\"12249320\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": null,
  "remote_org_id": 18,
  "error": false
}

PCR Forms

• get_pcr_json – Get PCR Form Information

get_pcr_json – Get PCR Form

The get_order event will return a work order and can contain a key named "pcr_forms". This key will contain an array of objects describing the forms assigned to the work order. The object will contain the following fields.

To retrieve the information for the form, use the get_pcr_json event.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_pcr_json",
  "event_data": "{\"pcr_form_id\":\"10066\",\"form_ver_id\":\"5\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_pcr_json",
    "event_data": "{\"pcr_form_id\":\"10066\",\"form_ver_id\":\"5\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

The data returned will contain the full information about the PCR form. This includes some basic form info, questions, question answer options for single and multi selects, question rules, and photo rules.

The result_data field will contain an object with the key of the pcr_form_id that was requested. The options_pcr_forms field contains the basic info on the form. There are several fields that will not be useful but are provided for completeness.

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "10066": {
      "options_pcr_forms": {
        "pcr_form_id": "10066",
        "org_id": "18",
        "pcr_form_name": "*** TEST SKIP LOGIC",
        "default_required": "1",
        "form_photos_required": "0",
        "transfer_prev_values": "0",
        "client_new_wo": "0",
        "global_form": "0",
        "web_template": "",
        "fillable_pdf": "",
        "pcr_form_active": "1",
        "pruvan_ver": "0",
        "thirdparty_id": "",
        "form_deleted": "0",
        "form_share_name": "_TEST_SKIP_LOGIC",
        "pruvan_master_id": "",
        "insert_by": "55",
        "insert_date": "2017-03-21 09:21:27",
        "publish_changes": "1",
        "inspectorade_id": null,
        "cyprexx_id": null,
        "pruvan_id": null
      }
    }
  }
}

PCR Questions

The questions object contains the following data. This should allow you to recreate the form on your own system and have the same options and functionality as PPW.

Response JSON Cont.

  "options_pcr_forms_questions": {
    "853007": {
      "pcr_question_id": "853007",
      "pcr_form_id": "10066",
      "question_num": "",
      "question_name": "Name",
      "question_desc": "",
      "question_type": "textbox",
      "question_data_type": "varchar",
      "question_display_active": "1",
      "question_required": "1",
      "question_na_option": "0",
      "question_flag_photos": "0",
      "question_photos_required": "0",
      "question_active": "0",
      "question_deleted": "1",
      "question_form_length": "",
      "question_order": "1.00",
      "pdf_field_id": "0",
      "thirdpartyfield_id": "0",
      "question_share_name": "Name",
      "question_transfer_prev_values": "0",
      "question_show_prev_values": "0",
      "question_auto_transfer_prev_values": "0",
      "question_field_rules_cnt": "0",
      "question_action_rules_cnt": "0",
      "question_photo_rules_cnt": "0",
      "insert_by": "55",
      "insert_date": "2017-03-21 08:49:34"
    },
    "853116": {
      "pcr_question_id": "853116",
      "pcr_form_id": "10066",
      "question_num": "",
      "question_name": "Able to access property."
      ...
  }

The PCR form question types are described below.

The PCR form question data types are described below.

PCR Question Options

Questions of type checkbox, dropdown and radio will all have options in the options_pcr_forms_questions_values field. This field is an array of all the options for all questions. They are not ordered or grouped in a specific way. You can loop through all the items and associate them as needed.

Response JSON Cont.

  "options_pcr_forms_questions_values": {
    "1238051": {
      "question_value_id": "1238051",
      "pcr_question_id": "853116",
      "question_value": "Yes",
      "pdf_field_id": "0",
      "question_value_active": "1",
      "thirdparty_value_id": "0",
      "question_share_value": null
    },
    "1238052": {
      "question_value_id": "1238052",
      "pcr_question_id": "853116",
      "question_value": "No",
      "pdf_field_id": "0",
      "question_value_active": "1",
      "thirdparty_value_id": "0",
      "question_share_value": null
    }
  },

PCR Question Rules

The rules for questions have two options. There are filed rules and action rules. Field rules determine how a question should be answered. Ex. answer must be greater than 2 and less than 12. Or you must select at least 3 of the 10 options. Action rules determine what other questions should be shown or hidden based on a question answer.

Action rules will have additional information in a field called options_pcr_forms_rules_checks. This field will be described further in the documentation.

Response JSON Cont.

  "options_pcr_forms_rules": {
    "22993": {
      "pcr_form_rule_id": "22993",
      "pcr_form_id": "10066",
      "pcr_question_id": "853116",
      "rule_type": "action",
      "rule_operator": "=",
      "rule_value": "",
      "insert_by": "55",
      "insert_date": "2017-03-30 12:03:55"
    },
    "22994": {
      "pcr_form_rule_id": "22994",
      "pcr_form_id": "10066",
      "pcr_question_id": "873273",
      "rule_type": "action",
      "rule_operator": "=",
      "rule_value": "1236968",
      "insert_by": "55",
      "insert_date": "2017-03-29 23:32:19"
    },
    "24131": {
      "pcr_form_rule_id": "24131",
      "pcr_form_id": "10066",
      "pcr_question_id": "877718",
      "rule_type": "field",
      "rule_operator": "length_greater_than",
      "rule_value": "2",
      "insert_by": "55",
      "insert_date": "2017-04-08 09:04:49"
    }
  },

The rule operator types are described below.

The field options_pcr_forms_rules_checks determines what action is taken when the rule is matched. The actions are either show or hide. The JSON and fields are described below.

Response JSON Cont.

  "options_pcr_forms_rules_checks": {
    "43819": {
      "pcr_rule_check_id": "43819",
      "pcr_form_rule_id": "22993",
      "pcr_question_id": "873273",
      "check_operator": "show",
      "check_value": "",
      "insert_by": "55",
      "insert_date": "2017-03-21 08:48:46"
    },
    "43820": {
      "pcr_rule_check_id": "43820",
      "pcr_form_rule_id": "22994",
      "pcr_question_id": "853121",
      "check_operator": "show",
      "check_value": "",
      "insert_by": "55",
      "insert_date": "2017-03-21 08:49:15"
    },
    "46739": {
      "pcr_rule_check_id": "46739",
      "pcr_form_rule_id": "24132",
      "pcr_question_id": "853121",
      "check_operator": "show",
      "check_value": "",
      "insert_by": "55",
      "insert_date": "2017-04-08 15:07:56"
    }
  },

Photo rules for the form are contained in the field options_pcr_forms_photo_rules. Photo rules have a similar structure as the question field and action rules. Every question has a default photo rule. Photo rules have a min and max for the photo requirements. If a rule has a min set to zero, then photos are not required for the question. If the max is also set to zero, then photos can not be taken for the question. If the min is greater than 0.

Response JSON Cont.

  "options_pcr_forms_photo_rules": {
    "24765": {
      "pcr_photo_rule_id": "24765",
      "pcr_question_id": "853007",
      "rule_operator": "default",
      "rule_value": "default",
      "take_photo": "0",
      "require_photo": "0",
      "min_photo": "0",
      "max_photo": "20",
      "insert_by": "55",
      "insert_date": "2017-03-21 08:49:34"
    },
    "59201": {
      "pcr_photo_rule_id": "59201",
      "pcr_question_id": "877718",
      "rule_operator": "=",
      "rule_value": "red",
      "take_photo": "0",
      "require_photo": "0",
      "min_photo": "5",
      "max_photo": "10",
      "insert_by": "55",
      "insert_date": "2017-04-08 09:25:08"
    },
    "59203": {
      "pcr_photo_rule_id": "59203",
      "pcr_question_id": "877718",
      "rule_operator": "default",
      "rule_value": "default",
      "take_photo": "0",
      "require_photo": "0",
      "min_photo": "1",
      "max_photo": "5",
      "insert_by": "55",
      "insert_date": "2017-04-08 09:25:08"
    }
  }

Bid/Comp & Invoice Items

• get_invoice_items_order – Get Bid/Comp & Invoice Items

get_invoice_items_order – Get Bid/Comp & Invoice Items

The valid Bid/Comp and Invoice options for the work order are available through the get_invoice_items_order event. Each work order could have a custom list of invoice options based on rules setup by each PPW customer. This function should be called for each order if you plan on using the invoicing function of PPWL. The result_data field contains a list of objects with the invoice_item_id and the Item Description. The first item usually has an id of zero and no description. This item can be ignored. The last item is usually “other”. This means the other item is allowed and users can add their own items to the invoice.

The invoice line items are retrieved using this event.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_invoice_items_order",
  "event_data": "{\"report_id\":\"12249320\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_invoice_items_order",
    "event_data": "{\"report_id\":\"12249320\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "0": "",
    "42839": "Exterior Inspection",
    "42838": "aaaaaaa",
    "42835": "11111",
    "42766": "REO Package - Basic",
    "42765": "Lock Change - Lockset",
    "42764": "Lock Change - Knob",
    "42759": "Carpet Replacement",
    "35929": "BID ITEM TEST",
    "8519": "Basements \/ Pools Needing Pumped",
    "8518": "Debris Exterior",
    "8517": "Debris Interior",
    "8523": "Grass Recut",
    "8522": "Initial Grass Cut",
    "8524": "Inspection",
    "8525": "Locks",
    "8514": "Lock Boxes",
    "8513": "Padlocks",
    "8520": "Rooms With Mold",
    "18560": "Test Drop down",
    "8521": "Trip Charge",
    "8515": "Winterization (Dry)",
    "8516": "Winterization (Wet)",
    "18561": "drop down option for demo",
    "42841": "test cancel item",
    "  ": "",
    "***other***": "Other"
  }
}

Photo / Docs

• get_file – Get Document(s) for a Specific Work Order

get_file – Get Documents

The get_file event retrieves files saved to a work order in PPW. These can be from one of two types, specified as the module_type: job_notes are Job Note attachments and uploads is for files saved in the Photos & Documents section. These files are passed as a presigned url with an expiration of 30 minutes from time of creation.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_file",
  "event_data": "{\"remote_report_id\":\"12249320\",\"report_id\":\"12236327\", \"module_type\":\"uploads\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_file",
    "event_data": "{\"remote_report_id\":\"12249320\",\"report_id\":\"12236327\",\"module_type\":\"uploads\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "b2793f7e-319a-4d64-9d0f-6b1e87c651c6",
  "success": true,
  "return_error_msg": null,
  "result_data": [{
    "remote_report_id": "0",
    "report_id": "59879",
    "file_id": 21960,
    "file_name": "48271_client_estimate-1.pdf",
    "file_type": "application/pdf",
    "file_size": "2",
    "file_desc": "",
    "s3_url": "https://link\to\file",
    "s3_url_thumb": "https://link\to\thumbnail",
    "module_type": "uploads",
    "org_name": "DEMO",
    "imported": 1
  }],
  "remote_org_id": 18,
  "error": false
}

Job Notes

• get_notes – Get All Job Notes for a Work Order

get_notes – Get Job Notes

Job notes can be sent via PPWLink by initiating the get_notes event. This event takes 2 inputs: A report_id and a remote_report_id. The report_id is the PPW work order from which you want to fetch the job notes from. The remote_report_id is the PPW work order to which you want the job notes to be posted. The types of these notes can be “wo” for work order note or “prop” for property notes.

For this event to fire, the Job Notes Import needs to be active. This can be done in the Auto Import. When active there needs to be at least one note group set. The groups selected here will be given permission to view the notes created by this import.

Request payload JSON

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "get_notes",
  "event_data": "{\"remote_report_id\":\"154687\",\"report_id\":\"122367\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "get_notes",
    "event_data": "{\"remote_report_id\":\"154687\",\"report_id\":\"122367\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "note_id": 1843,
      "note_rev": 0,
      "report_id": 45321,
      "remote_report_id": 154687,
      "note_type": "wo",
      "note_text": "Some Note Text",
      "insert_by": "USER_ID Of User who created the note",
      "insert_date": "2024-09-19 12:07:03",
      "org_name": "PPW Organization",
      "has_attachments": "True"
    },
    {
      "note_id": 1844,
      "note_rev": 1843,
      "report_id": 45321,
      "remote_report_id": 154687,
      "note_type": "wo",
      "note_text": "Some Note Text. Edited",
      "insert_by": 131667,
      "insert_date": "2024-09-19 12:08:03",
      "org_name": "PPW Organization",
      "has_attachments": "True"
    }

  ]
}

Send Results Introduction

Sending results through PPWL includes, photos, files attachments, mobile check in, PCR form answers, Bid/Completion lines, Contractor Invoices and marking orders Ready for Office. Work orders that are marked Ready for Office, Invoiced, or Complete can not have results sent to them through PPWLink.

Originating Data / Creating New Orders

PPWL can be used to create new work orders, along with PCR Forms, and Invoice Line Items. This enables an integrator to act as a PPW account, create orders, and receive the results of those work orders, through PPWL.

The previous section of the documentation that describes how to retrieve information from PPWL can be used to develop your receiver script. All PPWL calls will go to a script called receiver. It can have any extension (.php, .aspx, .jsp, .py) or none.

Example URLs:

https://www.mysite.com/api/receiver.aspx

https://www.mysite.com/ppwl/receiver

Send Results Work Order

• get_all_orders – Send New Work Orders
• get_all_updates – Update Existing Work Order. Includes RTV and Complete/Cancel
• send_date_est – Set Estimated Complete Date for a Work Order
• send_ready_for_office – Set Work Order to RFO Status
• send_checkin – Send Check In Data

get_all_orders – Sending New Orders

The get_all_orders event is meant to send all open orders assigned to the account. The optional timestamp field in the event_data is used to only send new or modified orders after the timestamp sent. The timestamp is UTC time. If the integrator’s system can support it, this can reduce the amount of data being accessed and sent.

Request payload JSON - get_all_orders

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
  "event_name": "get_all_orders",
  "event_data": "{\"timestamp\":\"1491699142\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
    "event_name": "get_all_orders",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

The response will contain an array of objects for each work order. The result data will have the report_id, wo_number, org_wo_num, wo_status, and transaction_id. PPW uses the report_id to track the order and return the results back to the correct order. The report_id should be a unique ID from the integrator’s system. The report_id needs to be an unsigned integer. The wo_number needs to be a unique value for the client company the import is assigned to in PPW. Because multiple client companies could have the same wo_number, this field is not verified to be unique across the users PPW account, just to the client company assigned to the PPWL import.

Field descriptions.

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "report_id": "12249320",
      "wo_number": "import test 3-1",
      "org_wo_num": "2272",
      "wo_status": "Unread",
      "transaction_id": "6e0fc218-d7c1-480d-82e5-0630d134a483"
    },
    {
      "report_id": "12249453",
      "wo_number": "import test 3-5",
      "org_wo_num": "2298",
      "wo_status": "Unread",
      "transaction_id": "ba1d10ab-fe52-4022-9a7a-f92643f774bb"
    },
    {
      "report_id": "12249455",
      "wo_number": "import test 3-6",
      "org_wo_num": "2299",
      "wo_status": "Unread",
      "transaction_id": "0b85961d-2295-42da-b0c7-36837c4f51e3"
    },
    {
      "report_id": "12249459",
      "wo_number": "import test 3-7",
      "org_wo_num": "2300",
      "wo_status": "Unread",
      "transaction_id": "e69dc54b-c624-4943-bc9d-6bb5fec0ffd2"
    },
    {
      "report_id": "12249473",
      "wo_number": "import test 3-7",
      "org_wo_num": "2301",
      "wo_status": "Unread",
      "transaction_id": "8cefa2e6-2f62-4715-a5df-0a6c8699fb8e"
    },
    {
      "get_all_updates": "1"
    },
    {
      "get_all_notes": "1"
    }
  ]
}

Based on the result of the get_all_orders event, any new orders will be requested using the get_order event.

If a transaction_id is passed PPW will respond with a ack_transaction event after the event has been processed. If a new work order is being sent, the acknowledgement will not come until after the get_order event has been called. The same transaction_id should be passed in the get_order event as was passed in the get_all_orders event.

If a duplicate order is detected in the get_all_orders event and a transaction_id is passed, PPW will respond with an ack_transaction event indicating the transaction_id and the reason why the order could not be imported.

If an object is sent with the value get_all_updates set to 1, then PPW will queue an event called get_all_updates. This event is described below in the Update Existing Orders section. Order updates can be sent with either the get_all_orders or get_all_updates event. This functionality allows the integrator to decide how the process is handled and logically separate them.

If an object is sent with the value get_all_notes set to 1, then PPW will queue an event called get_all_notes. Check

get_all_updates – Update Existing Orders

Work orders can be updated by sending the order again in the get_all_orders event with a specific wo_status and additional information about what needs updated. PPW will check that the work order is valid and still in an open status. The work order will not be updated if its status is Ready for Office, Invoiced, or Complete. If the field is the same, it will not be updated. The exception is the line_items. These will always replace the existing items. If the work order is updated, a new import log will be saved.

Fields that can be updated are

• address
• loan_type_other
• city
• lock_code
• comments
• lot_size
• cust_text
• mortgage_name
• date_due
• start_date
• key_code
• state
• line_items
• vendor_id
• loan_number
• zip

Request payload JSON - get_all_updates

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
  "event_name": "get_all_updates",
  "event_data": "{\"timestamp\":\"1491699142\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
    "event_name": "get_all_updates",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "report_id": "12249320",
      "wo_number": "import test 3-1",
      "org_wo_num": "2272",
      "wo_status": "Update",
      "update_field": "lot_size",
      "update_value": "45,000 sqft",
      "transaction_id": "57965ecc-524a-11e9-8647-d663bd873d93"
    },
    {
      "report_id": "12249453",
      "wo_number": "import test 3-5",
      "org_wo_num": "2298",
      "wo_status": "Update",
      "update_field": "vendor_id",
      "update_value": "johnsmith",
      "transaction_id": "62163786"
    }
  ]
}

Complete or Cancel Orders

Work orders can be marked complete or canceled using the wo_status of Complete or Cancel.

Response JSON

{
   "remote_site_id":"1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
   "error":false,
   "success":true,
   "return_error_msg":null,
   "result_data":[
      {
         "report_id":"12249320",
         "wo_number":"import test 3-1",
         "org_wo_num":"2272",
         "wo_status":"Complete",
         "transaction_id":"57965ecc-524a-11e9-8647-d663bd873d93"
      }
   ]
}

Return to Vendor (Follow Up)

Work orders can be returned to the vendor (RTV) by setting the wo_status to RTV. The reason for the followup can be passed in the update_value field.

Response JSON

{
   "remote_site_id":"1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
   "error":false,
   "success":true,
   "return_error_msg":null,
   "result_data":[
      {
         "report_id":"12249320",
         "wo_number":"import test 3-1",
         "org_wo_num":"2272",
         "wo_status":"RTV",
         "update_field":"",
         "update_value":"Take better photos of exterior debris.",
         "transaction_id":"57965ecc-524a-11e9-8647-d663bd873d93"
      }
   ]
}

send_date_est – Set Estimated Complete Date

Limited availability. Not enabled for all accounts.

Work orders that have an estimated complete date set on them will have this information automatically sent back to the originating work order.

Request payload JSON - send_date_est

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_date_est",
  "event_data": " {\"dst_report_id\":\"12249481\",\"date_complete_estimate\":\"20200402\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_date_est",
    "event_data": "{\"dst_report_id\":\"12249481\",\"date_complete_estimate\":\"20200402\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": null,
  "remote_org_id": 283,
  "error": false
}

send_ready_for_office – Set Ready for Office

Work orders are set as ready for Office using the send_ready_for_office event. This will validate the work order PCR forms, photos and any other requirements set by the PPW customer. Only the dst_report_id is passed. The result will contain any errors the function returned. These are the same errors that would normally be returned when setting a work order as Ready for Office from the website.

Request payload JSON - send_ready_for_office

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_ready_for_office",
  "event_data": "{\"dst_report_id\":\"12249481\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_ready_for_office",
    "event_data": "{\"dst_report_id\":\"12249481\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Reponse JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "error": [],
    "cell_updates": [{
      "report_id": "12249481",
      "cell_id": "wo_status",
      "new_value": "Ready for Office",
      "class": "wo_status__ready"
    }],
    "error_reportid": [],
    "records_updated": "1",
    "ready_update": "07-14-2025 10:52 AM by USER",
    "log_code": "10|10111120:s:010"
  },
  "remote_org_id": 283,
  "error": false
}

send_checkin – Sending Check In Data

The check in data sent will always include the latitude, longitude, and timestamp. The accuracy, high accuracy and misc_data may not always be available based on the type of check in for the work order. The standard PPW check in will not have data in msic_data. Work orders set to AGS or ServiceLink check in, will contain additional data in JSON format.

The details of the JSON object are described below.

Check In Data

Request payload JSON - send_checkin

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_checkin",
  "event_data": " {\"dst_report_id\":\"12249481\",\"checkin_data\":{\"bg_check_id\":null,\"ch eckin_ts\":\"2019-02-01 06:42:17\",\"gps_lat\":\"38.2078462\",\"gps_lng\":\"-65.1647053\",\"gps_accuracy\":\"23\",\"gps_high_accuracy\":\"\",\"misc_data \":\"\"}}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_checkin",
    "event_data": "{\"dst_report_id\":\"12249481\",\"checkin_data\":{\"bg_check_id\":null,\"checkin_ts\":\"2019-02-01 06:42:17\",\"gps_lat\":\"38.2078462\",\"gps_lng\":\"-65.1647053\",\"gps_accuracy\":\"23\",\"gps_high_accuracy\":\"\",\"misc_data\":\"\"}}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Reponse JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": null,
  "remote_org_id": 283,
  "error": false
}

PCR Form

• send_pcr_answers – Send PCR Results
• send_photo_flag – Associate (flag) photos to PCR Questions and Bid/Comp Items

send_pcr_answers – Sending PCR Results

The PCR form results are sent using the information from the PCR forms JSON. The question data type and the question ID is sent with every answer object.

Request payload JSON - send_pcr_answers

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_pcr_answers",
  "event_data": "{\"dst_report_id\":\"14413749\",\"pcr_form_id\":\"76\",\"pcr_ form_rows\":[ {\"pcr_question_id\":\"6716\",\"question_data_type\":\"varchar\",\"varchar_ value\":\"hello!!!\"},{\"pcr_question_id\":\"14243098\",\"question_data_type\":\"varchar\", \"varchar_value\":\"nothing to see here\"}, {\"pcr_question_id\":\"14243099\",\"question_data_type\":\"int\",\"int_valu e\":\"30932050\"}, {\"pcr_question_id\":\"1027910\",\"question_data_type\":\"date\",\"date_value\":\"2017-04-06\"}, {\"pcr_question_id\":\"877651\",\"question_data_type\":\"longtext\",\"longtext_value\":\"hello!!!\"} ]}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_pcr_answers",
    "event_data": "{\"dst_report_id\":\"14413749\",\"pcr_form_id\":\"76\",\"pcr_form_rows\":[{\"pcr_question_id\":\"6716\",\"question_data_type\":\"varchar\",\"varchar_value\":\"hello!!!\"},{\"pcr_question_id\":\"14243098\",\"question_data_type\":\"varchar\",\"varchar_value\":\"nothing to see here\"},{\"pcr_question_id\":\"14243099\",\"question_data_type\":\"int\",\"int_value\":\"30932050\"},{\"pcr_question_id\":\"1027910\",\"question_data_type\":\"date\",\"date_value\":\"2017-04-06\"},{\"pcr_question_id\":\"877651\",\"question_data_type\":\"longtext\",\"longtext_value\":\"hello!!!\"}]}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Question type checkbox requires each answer to be sent as an individual record in the event data. There will be multiple entries for the pcr_question_id. An example payload is below. The first three entries represent what the data should look like.

Request payload JSON - checkbox example - send_pcr_answers

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_pcr_answers",
  "event_data": "{\"dst_report_id\":\"14413749\",\"pcr_form_id\":\"76\",\"pcr_ form_rows\":[ {\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_value\": \"1\"},{\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_va lue\":\"2\"}, {\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_value\":\"3\"}, {\"pcr_question_id\":\"6717\",\"question_data_type\":\"date\",\"date_value\":\"2017-04-06\"}, {\"pcr_question_id\":\"6718\",\"question_data_type\":\"longtext\",\"longtex t_value\":\"hello!!!\"} ]}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_pcr_answers",
    "event_data": "{\"dst_report_id\":\"14413749\",\"pcr_form_id\":\"76\",\"pcr_form_rows\":[{\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_value\":\"1\"},{\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_value\":\"2\"},{\"pcr_question_id\":\"6716\",\"question_data_type\":\"int\",\"int_value\":\"3\"},{\"pcr_question_id\":\"6717\",\"question_data_type\":\"date\",\"date_value\":\"2017-04-06\"},{\"pcr_question_id\":\"6718\",\"question_data_type\":\"longtext\",\"longtext_value\":\"hello!!!\"}]}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

send_photo_flag – Sending Photo Flag Info

Associating photos with Bid/Completion items or PCR questions is called “flagging” in PPW. To flag photos to PCR questions, you must send a request with the following fields.

The photo flagging details are described below.

Request payload JSON - send_photo_flag

{
   "username":"demo",
   "password":"da39a3ee5e6b4b0d3255bfef95601890afd80709",
   "site_id":"dcc363d0-8ed1-48a2-ba2e-f638275db4f",
   "event_name":"send_photo_flag",

"event_data":"{\"dst_report_id\":\"12249481\",\"pcr_form_id\":\"10086\",\"question_data\":[
{\"file_id\":\"1130171565\",\"pcr_question_id\":\"877651\",\"work_type\":\" pc\"},
{\"file_id\":\"1130171566\",\"pcr_question_id\":\"877651\",\"work_type\":\" pc\"},
{\"file_id\":\"1130171567\",\"pcr_question_id\":\"877652\",\"work_type\":\" pc\"}]}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_photo_flag",
    "event_data": "{\"dst_report_id\":\"12249481\",\"pcr_form_id\":\"10086\",\"question_data\":[{\"file_id\":\"1130171565\",\"pcr_question_id\":\"877651\",\"work_type\":\"pc\"},{\"file_id\":\"1130171566\",\"pcr_question_id\":\"877651\",\"work_type\":\"pc\"},{\"file_id\":\"1130171567\",\"pcr_question_id\":\"877652\",\"work_type\":\"pc\"}]}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Multiple photos can flagged in a single call. There is no limit on the number of records that can be sent at once.

Send Results Bid/Comp & Invoice Items

• send_bid_comp – Send Bid/Completion Results
• send_contractor_invoice – Send Contractor Invoice
• bid_comp_confirm – Send Empty Bid/Comp Confirmation

send_bid_comp – Sending Bid/Completion Results

Bid and Completion items are sent using the send_bid_comp event. An item can be flagged as a bid and a completion in the same call. Or you can send them in separate calls. The ability to have a bid and completion tied to the same comp_note_id is for legacy support.

Request payload JSON - send_bid_comp

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_bid_comp",
  "event_data": "{\"dst_report_id\":\"123456789\",\"dest_invoice_item_id\":\"\",\"src_invoice_item_id\":\"101\",\"invoice_item_desc\":\"HVAC\",\"qty_bid\":\"1\",\"client_price_bid\":\"360.00\",\"bid_note\":\"Service furnace and AC unit.\",\"qty_comp\":\"\",\"comp_note\":\"\",\"photo_flag_data\":[{\"file_id\":\"1506814912\",\"work_type\":\"b\",\"stage\":\"b\"},{\"file_id\":\"1506814913\",\"work_type\":\"c\",\"stage\":\"b\"},{\"file_id\":\"1506814914\",\"work_type\":\"c\",\"stage\":\"i\"},{\"file_id\":\"1506814915\",\"work_type\":\"c\",\"stage\":\"a\"}],\"remote_id\":\"\",\"total_items\":5,\"cur_index\":2}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_bid_comp",
    "event_data": "{\"dst_report_id\":\"123456789\",\"dest_invoice_item_id\":\"\",\"src_invoice_item_id\":\"101\",\"invoice_item_desc\":\"HVAC\",\"qty_bid\":\"1\",\"client_price_bid\":\"360.00\",\"bid_note\":\"Service furnace and AC unit.\",\"qty_comp\":\"\",\"comp_note\":\"\",\"photo_flag_data\":[{\"file_id\":\"1506814912\",\"work_type\":\"b\",\"stage\":\"b\"},{\"file_id\":\"1506814913\",\"work_type\":\"c\",\"stage\":\"b\"},{\"file_id\":\"1506814914\",\"work_type\":\"c\",\"stage\":\"i\"},{\"file_id\":\"1506814915\",\"work_type\":\"c\",\"stage\":\"a\"}],\"remote_id\":\"\",\"total_items\":5,\"cur_index\":2}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

The details of the JSON object are described below.

Photo Flag Data Fields

The response result_data will contain the comp_note_id of the created record. This comp_note_id can be used to update the item if needed. Bid/Comp items can only be updated while order is open and still assigned to the contractor.

Response JSON

{
   "remote_site_id":"1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
   "error":false,
   "success":true,
   "return_error_msg":null,
   "result_data": {"comp_note_id":10161276}
}

bid_comp_confirm – Sending Empty Bid/Completion Confirmation

If the option Send Empty Bid/Comp Confirmation is enabled in the Auto Import setup in PPW and the order contains no Bid/Comp items to send, an event called bid_comp_confirm will be sent. The event_data will contain the report_id of the order.

Request payload JSON - bid_comp_confirm

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "bid_comp_confirm",
  "event_data": "{\"dst_report_id\": \"123456789\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "bid_comp_confirm",
    "event_data": "{\"dst_report_id\": \"123456789\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

send_contractor_invoice – Sending Contractor Invoice

The contractor invoice is mapped from your system to PPW by using the invoice_item_id from the get_invoice_items_order function.

The details of the JSON object are described below.

Invoice Lines

Request payload JSON - send_contractor_invoice

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_contractor_invoice",
  "event_data": "{\"dst_report_id\":\"12250009\",\"dst_invoice_item_ids\":{\"12880771\":\"***other***\"},\"comment\":\"\",\"invoice_lines\":[{\"line_id\":\"12880771\",\"invoice_item_id\":\"42766\",\"quantity\":\"1.00\",\"price\" :\"500.00\",\"item_desc\":\"REO Package - Basic\",\"flat_fee\":\"0\"}]}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_contractor_invoice",
    "event_data": "{\"dst_report_id\":\"12250009\",\"dst_invoice_item_ids\":{\"12880771\":\"***other***\"},\"comment\":\"\",\"invoice_lines\":[{\"line_id\":\"12880771\",\"invoice_item_id\":\"42766\",\"quantity\":\"1.00\",\"price\":\"500.00\",\"item_desc\":\"REO Package - Basic\",\"flat_fee\":\"0\"}]}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "line_ids_cont": {
      "invoice_id": 12345,
      "line_ids": [9876]
    }
  },
  "remote_org_id": 283,
  "error": false
}

Send Results Photo/Docs

• send_file – Send Photo/File

send_file – Sending a Photo or File

Attaching photos or files to a work order is done through the send_file event.

Files can be sent two ways.

1. Files should be sent using multipart/form-data with the “file” field name. The POST data should contain four fields. The dst_report_id, file_id, file_name, and file_area.

Request payload JSON - multipart/form-data

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_file",
  "event_data": "{\"dst_report_id\":\"12249481\",\"file_id\":\"1130171565\",\"file_area\":\"0\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_file",
    "event_data": "{\"dst_report_id\":\"12249481\",\"file_id\":\"1130171565\",\"file_area\":\"0\"}"
  }' \
  https://devas.propertypreswizard.com/main/api/link/receiver.php

2. A URL accessible to PPW can be sent in the payload for the image and thumbnail. When PPW sends results back to a third party, this method is used.

Request Payload JSON - URL Accessible

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_file",
  "event_data": "{\"dst_report_id\":\"12249481\",\"file_id\":\"1130171565\",\"file_area\":\"0\",\"file_name\":\"example.jpg\",\"s3_url\":\"https://your-bucket.s3.amazonaws.com/example.jpg\",\"s3_url_thumb\":\"https://your-bucket.s3.amazonaws.com/example_thumb.jpg\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_file",
    "event_data": "{\"dst_report_id\":\"12249481\",\"file_id\":\"1130171565\",\"file_area\":\"0\",\"file_name\":\"example.jpg\",\"s3_url\":\"https://your-bucket.s3.amazonaws.com/example.jpg\",\"s3_url_thumb\":\"https://your-bucket.s3.amazonaws.com/example_thumb.jpg\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

The file_id passed to the PPWL web service should be the unique ID from the integrator’s system. When photos are flagged to Bid/Completion items or PCR form questions, the integrator will send the same ID from their end and PPWL will look up the information and associate the photos correctly.

Allowed File Types

Job Notes

• send_notes – Send Job Note(s)
• get_all_notes – Get All Job Note(s)

send_notes – Send Job Notes

Job Notes can now be sent back to the client by initiating the send_notes event. Note MUST be wrapped in a note object. View the Request Payload below for an example.

The details of the JSON object are described below.

Note object fields

Request payload JSON – send_notes

{

  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
  "event_name": "send_notes",
  "event_data": {
    "dst_report_id": "12345",
    "org_name": "Sample Org Name",
    "module_type": "job_notes",
    "note": [{
      "note_id": "67890",
      "note_rev": "56789",
      "note_type": "wo",
      "note_text": "This is a sample note text.",
      "insert_date": "2025-01-06T12:00:00Z",
      "has_attachments": true
    }]
  }
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2-ba2e-f638275db4f",
    "event_name": "send_notes",
    "event_data": "{\"dst_report_id\":\"12345\",\"org_name\":\"Sample Org Name\",\"module_type\":\"job_notes\",\"notes\":[{\"note_id\":\"67890\",\"note_rev\":\"56789\",\"note_type\":\"wo\",\"note_text\":\"This is a sample note text.\",\"insert_date\":\"2025-01-06T12:00:00Z\",\"has_attachments\":true},{\"note_id\":\"67891\",\"note_rev\":\"56790\",\"note_type\":\"wo\",\"note_text\":\"This is a second sample note for testing.\",\"insert_date\":\"2025-01-07T15:30:00Z\",\"has_attachments\":false}]}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "success": true,
  "return_error_msg": null,
  "result_data": {
    "remote_note_id": 42
  },
  "remote_org_id": 283,
  "error": false
}

get_all_notes – Get All Job Notes

New job notes can be sent to PPW by initiating the get_all_notes event. See Sending New Orders for information on this.

An array of objects containing the job notes can be sent at once. These notes will be created in PPW and an acknowledgement will be sent back if a transaction_id was sent. Job notes can be work order or property notes. The distinction in PPW is a property note will show for all orders at the same property. A work order note will only show for the specific work order it was associated with. Multiple job notes to multiple orders can all be sent at the same time.

Request payload JSON - get_all_notes

{
  "username": "demo",
  "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
  "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
  "event_name": "get_all_notes",
  "event_data": "{\"timestamp\":\"1491699142\"}"
}

curl -X POST \
  --data 'payload={
    "username": "demo",
    "password": "da39a3ee5e6b4b0d3255bfef95601890afd80709",
    "site_id": "dcc363d0-8ed1-48a2ba2e-f638275db4f",
    "event_name": "get_all_notes",
    "event_data": "{\"timestamp\":\"1491699142\"}"
  }' \
  https://www.propertypreswizard.com/api/link/receiver.php

Response JSON - get_all_notes

{
  "remote_site_id": "1fc25d06-72bd-42f8-ad34-ecbdc5f1a4a4",
  "error": false,
  "success": true,
  "return_error_msg": null,
  "result_data": [{
      "wo_number": "12113528",
      "note_id": "rhudf-5196-dfsdf-095mwf",
      "note_type": "wo",
      "note_text": "Test Note. 1",
      "note_from": "XFS",
      "transaction_id": "sd1sdf-1624-dfsdf-435fgdf"
    },
    {
      "wo_number": "12113528",
      "note_id": "sds1df-5196-dfsdf-435fgdf",
      "note_type": "wo",
      "note_text": "Test Note. 2",
      "note_from": "XFS",
      "transaction_id": "sd2sdf-5656-dfsdf-435fgdf"
    }
  ]
}
